Features
Screw barrel is specially hardened and very wear resistance.
Two-stage (mother and baby) exhaust type plastic extrusion can repeatedly discharge the gas generated after the material is heated.
Both extruders are designed with filter replacement devices, , which will filter out the impurities in the material.
The pellets made by our machine are firmer, smoother and more pure.
Our plastic granulator is most suitable for regenerative extrusion granulation high pressure polyethylene (LDPE), polypropylene (PP), HDPE, LLDPE, ABS, polystyrene (PS), etc. Our plastic pellete making machine can process plastic film, plastic bottle, woven bag, washed plastic, post consumer or post industrial gross raw material, etc.
Some models are designed with reference to foreign technology and according to our international situation, and have been adopted by customers.
The plastic pelletizer layout can design “straight I” or “L-shaped”.
15 years plastic recycling machine experience, factory directly full automatic waste plastic pelletizer machine.
Highest productivity and flexibility, low energy consumption, easiest operation.
Parameters
Mother and baby extruder machine configuration
（First stage extruder mother machine）
Model Screw diameter (mm) Screw length (mm) Venting type Screw drive power(kw) Heating zone Heating power (Kw) Output (kg/h)
SJ-120A 120 2300 Single exhaust 30-6 5 28 100-200
SJ-140A 140 2300 Single exhaust 37-6 6 40 150-300
SJ-140A 140 2600 Single exhaust 45-6 7 45 150-300
SJ-140A 140 3600 Single exhaust 55-6 9 65 180-375
SJ-150A 150 3000 Single exhaust 75-4 8 60 200-375
SJ-160A 160 3000 Single exhaust 75-4 8 65 230-400
SJ-180A 200 4200 Single exhaust 90-6 9 75 500-600
SJ-200A 280 5000 Single exhaust 160-6 12 140 800-1000
Remark: 1. 225-450 Gear Box, independent electric cabinet, 5.5Kw-30pcs blade cutter, 4m stainless steel water cooling tank. 2. Screw material is 38CrMoAlA, nitrogen harden, 40Cr barrel material.
The second stage baby machine gear box 225-330 standard type
SJ-120B 120 1500 Single exhaust 15-4 3 12 12
SJ-140B 140 1800 Single exhaust 22-4 4 18 18
SJ-200B 200 1600 None 45-4 5 25 25
SJ-220B 220 2200 None 55-6 6 35 35
Appliction
