The machine Adopt Taiwan and Italian techniques. It is mini-type of pelletizing line which is very popular for film blowing factory and film bag manufacturer. It is high automatic level pelletizing line and labour cost is also very low. It is compact design which take up very less space. It is mainly used for waste clean and drying PP/PE rope.
Features
ures:
The machine Adopt Taiwan and Italian techniques. It is mini-type of pelletizing line which is very popular for film blowing factory and film bag manufacturer.
It is high automatic level pelletizing line and labour cost is also very low. It is compact design which take up very less space.
It is mainly used for waste clean and drying PP/PE rope.
Parameters
Model GL600 GL800 GL1000 GL1200 GL1400 GL1600
Main shaft speed (rpm) 80-100 80-100 80-100 80-100 80-100 80-100
Effective length of main rotor (mm) 600 800 1000 1200 1400 1600
Rotor diameter (mm) Φ220 Φ400 Φ400 Φ400 Φ400 Φ500
Number of rotor blades (pcs) 60 90 108 190 250 280
Number of fixed blades (pcs) 8 8 8 8 8 8
Screen holes diameter (mm) 40 40 40 40 40 40
Motor power (kw) 18.5-22kw*2sets 37kw*2sets 45kw*2sets 75kw*2sets 90kw *2sets 110kw*2sets
Production capacity (kg/hour) 300-500 500 500-1000 1000-1500 1500 1500-2000
Appliction
