Features
Screw barrel is specially hardened and very wear resistance.
Two-stage (mother and baby) exhaust type plastic extrusion can repeatedly discharge the gas generated after the material is heated.
Both extruders are designed with filter replacement devices, , which will filter out the impurities in the material.
The pellets made by our machine are firmer, smoother and more pure.
Our plastic granulator is most suitable for regenerative extrusion granulation high pressure polyethylene (LDPE), polypropylene (PP), HDPE, LLDPE, ABS, polystyrene (PS), etc. Our plastic pellete making machine can process plastic film, plastic bottle, woven bag, washed plastic, post consumer or post industrial gross raw material, etc.
Some models are designed with reference to foreign technology and according to our international situation, and have been adopted by customers.
The plastic pelletizer layout can design “straight I” or “L-shaped”.
15 years plastic recycling machine experience, factory directly full automatic waste plastic pelletizer machine.
Highest productivity and flexibility, low energy consumption, easiest operation.
Parameters
Mother and baby extruder machine configuration
(First stage extruder mother machine)
Model
Screw diameter (mm)
Screw length (mm)
Venting type
Screw drive power(kw)
Heating zone
Heating power (Kw)
Output (kg/h)
SJ-120A
120
2300
Single exhaust
30-6
5
28
100-200
SJ-140A
140
2300
Single exhaust
37-6
6
40
150-300
SJ-140A
140
2600
Single exhaust
45-6
7
45
150-300
SJ-140A
140
3600
Single exhaust
55-6
9
65
180-375
SJ-150A
150
3000
Single exhaust
75-4
8
60
200-375
SJ-160A
160
3000
Single exhaust
75-4
8
65
230-400
SJ-180A
200
4200
Single exhaust
90-6
9
75
500-600
SJ-200A
280
5000
Single exhaust
160-6
12
140
800-1000
Remark: 1. 225-450 Gear Box, independent electric cabinet, 5.5Kw-30pcs blade cutter, 4m stainless steel water cooling tank. 2. Screw material is 38CrMoAlA, nitrogen harden, 40Cr barrel material.
The second stage baby machine gear box 225-330 standard type
SJ-120B
120
1500
Single exhaust
15-4
3
12
12
SJ-140B
140
1800
Single exhaust
22-4
4
18
18
SJ-200B
200
1600
None
45-4
5
25
25
SJ-220B
220
2200
None
55-6
6
35
35
Appliction
